Height: max 1.800 mm Pallet format: max 1.000 x 1.200 mm Speed: max 30 pallets/h Electrics: 380 VAC Electrics: 50 Hz Electrics: 3 PH holding power: max 5.500 N Equipment  • strapping machine: XP-112 MV • sealing head CFH-1 • stretch wrapper: GL-215 • control: S7

Type of pallet: Euro pallet max height of pallet 1450 mm (incl. pallet) Elektrik: 380 VAC, 3 PH, 50 Hz, 5,5 kW Masse (L x B x H): appr. 7500 x 1200 x 400 mm Gewicht: ~1000 kg Configuration: straight pallet conveying  Modules:  Position for two stacks of empty pallets  - separation of pallets - palletizing position  - pick-up position for full pallets

Cyklop Pallet strapping & film wrapping line: Cyklop XZE-311-22 pallet strapping Cyklop GL 1020M - pallet film wrapping  Build in 2010 (XZE-M) 2006 (GL 1020M)  Pallet strapper Cyklop XZE-311-22: Speed: up to 100 Palles/h Pallet sizes: 800x1200 mm, 1000x1200, 1200x1200 mm Passage height: max 2700 mm (from floor) min height pallet conveyors: 300 mm max palletizing height: ~2500 mm - height conveyors (incl. pallet) max weight pallet: 1.500 kg Height over all: ~4200 mm Elektrical: 400 VAC, 3Ph/N/PE, 50 Hz, ~6 kW Dimensions (L x W x H): appr. 2.000 x 7.000 (incl. strapping reels) x 4.200 mm Weight: ca. 4.000 kg  GL 1020M: Speed: up to 50 Pallets/h Pallet sizes: 800x1200 mm, 1000x1200, 1200x1200 mm Passage height: max 2200 mm (from bottom pallet) min height pallet conveyors: 300 mm Working height: 500 - 2000 mm (inkl. Palette) Film, outside (new) reel diameter: max 400 mm Film, reel width: max 500 mm Film thickness: 17/23/35 µm max pallet weight: 1.500 kg Elektrical: 400 VAC, 3Ph/N/PE, 50 Hz, ~3 kW Dimensions (L x W x H) : ca. 1.800 x 3.000 x 3.500 mm Weight: appr. 1.500 kg  Equipment: Complete line, "L"-configuration (long leg ~20m, short leg ~5m) for pallet strapping & stretch wrapping, configured as follows: > Infeed position for pallets, motorized > pallet strapper Cyklop XZE with two strapping heads, three strap guides, integrated turntable for cross-strapping of pallets > buffer position for pallets, motorized > pallet film wrapper Cyklop GL 1020, film dispensing through fix lateral arm with pallet rotating on turntable > buffer position for pallets, motorized > turntable for pallets, 90° turn left or right, motorized > ejection of the turned pallet onto pick-up positions, motorized SEE LAYOUT FOR MORE INFO

Cyklop Pallet strapping & film wrapping line: Cyklop XZE-311-22 pallet strapping Cyklop GL 1020M - pallet film wrapping  Build in 2000 (XZE-M) 2000 (GL 1020M)  Pallet strapper Cyklop XZE-311-22: Speed: up to 100 Palles/h Pallet sizes: 800x1200 mm, 1000x1200, 1200x1200 mm Passage height: max 2700 mm (from floor) min height pallet conveyors: 300 mm max palletizing height: ~2500 mm - height conveyors (incl. pallet) max weight pallet: 1.500 kg Height over all: ~4200 mm Elektrical: 400 VAC, 3Ph/N/PE, 50 Hz, ~6 kW Dimensions (L x W x H): appr. 2.000 x 7.000 (incl. strapping reels) x 4.200 mm Weight: ca. 4.000 kg  GL 1020M: Speed: up to 50 Pallets/h Pallet sizes: 800x1200 mm, 1000x1200, 1200x1200 mm Passage height: max 2200 mm (from bottom pallet) min height pallet conveyors: 300 mm Working height: 500 - 2000 mm (inkl. Palette) Film, outside (new) reel diameter: max 400 mm Film, reel width: max 500 mm Film thickness: 17/23/35 µm max pallet weight: 1.500 kg Elektrical: 400 VAC, 3Ph/N/PE, 50 Hz, ~3 kW Dimensions (L x W x H) : ca. 1.800 x 3.000 x 3.500 mm Weight: appr. 1.500 kg  Equipment: Complete line, "L"-configuration (long leg ~20m, short leg ~5m) for pallet strapping & stretch wrapping, configured as follows: > Infeed position for pallets, motorized > pallet strapper Cyklop XZE with two strapping heads, three strap guides, integrated turntable for cross-strapping of pallets > buffer position for pallets, motorized > pallet film wrapper Cyklop GL 1020, film dispensing through fix lateral arm with pallet rotating on turntable > buffer position for pallets, motorized > turntable for pallets, 90° turn left or right, motorized > ejection of the turned pallet onto pick-up positions, motorized SEE LAYOUT FOR MORE INFO

Built in 2000 Size: max 2.900 mm; min 500 mm Speed up to 120 pallets/h Cyclop Palettenumreifung & -wickler Cyklop Palettenumreifer mit 3 Umreifungspositionen, Drehteller und Presse XZE-311-27 Cyclop Palettenwickler, Ringtyp GL 1020 Cyklop Palettenumreifer mit 3 Umreifungspositionen, Drehteller und Presse XZE-311-22 Cyklop Palettenfördertechnik, gerade

Layer palletizer for stable (strapped) bundles. Bundle size : min 140-200mm, max 300-430mm  From one infeed line onto one pallet.  Infeed with blocking unit VB-95 and optionally 2 x walkway conveyors and flow turn to the right. Row building with bundle turning, transfer of rows and building of a complete layer. Palletizing of the layer onto pallet. Pallet conveying for EURO-pallets (800x1200mm) with empty pallet dispenser PT-80, palletizing position and pick-up for full pallets. Speed of up to 1500 bundles/h (stable bundles required!). Weight (palletizer + pallet conveying): ~ 3000 kg Power: 380-420 V, 3~, N, PE, 50 Hz Air: 0,35 Nm3/Min @ 6 bar

Layer palletizer for stable (strapped) bundles. Bundle size : min 140-200mm, max 300-430mm  From one infeed line onto one pallet.  Infeed with blocking unit VB-95 and optionally walkway conveyor and flow turn to the left. Row building with bundle turning, transfer of rows and building of a complete layer. Palletizing of the layer onto pallet. Pallet conveying for EURO-pallets (800x1200mm) with empty pallet dispenser PT-80, palletizing position and pick-up for full pallets. Speed of up to 1500 bundles/h (stable bundles required!). Weight (palletizer + pallet conveying): ~ 3000 kg Power: 380-420 V, 3~, N, PE, 50 Hz Air: 0,35 Nm3/Min @ 6 bar

Built in 2000 Complete line for automatic pallet strapping (double or cross), automatic stretch-wrapping of pallets. Includes fully automated pallet conveying. Line with ""L""-configuration, configured as follows: > Infeed position for pallets, motorized, l~2000mm, REF 26476.01 > pallet strapper Mosca KCK 211, l~2000mm, REF 26476.30 > pallet film wrapper Mosca WTR 3, l~1800mm, REF 26476.40 > buffer position for pallets, motorized, l~1500mm, REF 26476.02 > Turntable for pallets, 90°, motorized, l~2000mm, REF 26476.03 > pick-up positions for pallets, motorized, l~2000mm, REF 26476.04" Speed: up to 50 pallets/h Pallet conveying with roller conveyors Pallet width of up to 800 mm Pallet length of up to 1200 mm max height full pallet (max passage height, incl. pallet): ~2600 mm Height of pallet conveying (min=300mm): ~500 mm max weight full pallet: ~1500 kg Over all length equipment: ~9.300 mm Over all width equipment: ~3.300 mm Over all height equipment: ~4000 mm Voltage: 400 V, 3Ph, 50 Hz  26476.30 Mosca Pallet Strapper Compresses and straps full pallets. Strapping can be on long side and optionally also on short side (with 90° pallet turn). Pallets are on a roller conveyor and arrive short side first into the pallet strapper. max speed in pallets/h: 100 pallets/h Pallet width of up to 1200 mm Pallet length of up to 1200 mm max height full pallet (max passage height): ~2.600 mm Integrated turntable for pallets Height of pallet conveying (min=300mm): ~500 mm max weight full pallet: 1500 kg Amount of strapping coils/reels: 2 One strapping head Second strapping head, model: Two strap guides (strapping positions) Strapping material (PP,PET): PP Over all length equipment: ~9.300 mm Over all width equipment: ~3.300 mm Over all height equipment: ~4.000 mm Input Power: ~6kVA Voltage: 400 VAC, 3 Ph/N/PE, 50 Hz Weight: ~4000 kg  26476.40 Mosca Pallet Wrapper Stretch wrapping of full pallets to protect the load of the pallets. max speed in pallets/h: 50 pallets/h Type of film wrapping: rotating turntable Pallet width of up to 800 mm Pallet length of up to 1200 mm max height full pallet (max passage height): 2.600 mm Integrated turntable for pallets Height of pallet conveying (min=300mm): ~500 mm max weight full pallet: 1500 kg Over all length equipment: ~1800 mm Over all width equipment: ~2500 mm Input Power: ~3kVA Voltage: 400 VAC, 3 Ph, 50 Hz Air requirement: 6 bar Weight: 1500 kg Color: Mosca blue & orange  26476.01 Mosca Pallet Conveyors Pallet conveyor used in a pallet strapper / wrapper line. max speed in pallets/h: > 100 pallets / h Infeed conveyor with side guides/centering Driven by motor Length of conveyor in mm: ~2.000 mm Width of conveyor in mm: ~1.100 mm Height of pallet conveyor: ~500 mm max pallet width for this conveyor: 800 mm max pallet length for this conveyor: 1200 mm max weight full pallet: 1500 kg Diameter of rollers in mm: ~80 mm Distance (pitch) between rollers in mm: ~150 mm Conveyor equipped with photoeyes on infeed/outfeed Input Power: 0,55 kW Voltage: 400 V, 3 Ph, 50 Hz  26476.02 Mosca Pallet Conveyors Pallet conveyor used in a pallet strapper / wrapper line. max speed in pallets/h: > 100 pallets / h Straight conveyor Driven by motor Length of conveyor in mm: ~1.500 mm Width of conveyor in mm: ~1.100 mm Height of pallet conveyor: ~500 mm max pallet width for this conveyor: 800 mm max pallet length for this conveyor: 1200 mm max weight full pallet: 1500 kg Diameter of rollers in mm: ~80 mm Distance (pitch) between rollers in mm: ~150 mm Conveyor equipped with photoeyes on infeed/outfeed Input Power: 0,55 kW Voltage: 400 V, 3 Ph, 50 Hz   26476.03 Mosca Pallet Conveyors Turntable conveyor 90° used in a pallet strapper / wrapper line. max speed in pallets/h: > 100 pallets / h Turntable conveyor Driven by motor Length of conveyor in mm: ~1.800 mm Width of conveyor in mm: ~1.800 mm Height of pallet conveyor: ~500 mm max pallet width for this conveyor: 800 mm max pallet length for this conveyor: 1200 mm max weight full pallet: 1500 kg Diameter of rollers in mm: ~80 mm Distance (pitch) between rollers in mm: ~150 mm Conveyor equipped with photoeyes on infeed/outfeed Input Power: 0,55 kW Voltage: 400 V, 3 Ph, 50 Hz Color: Alu, grey  26476.04 Mosca Pallet Conveyors Pick-up conveyor with bump protection max speed in pallets/h: > 100 pallets / h Pick-up conveyor with side guides & bump protection Driven by motor Length of conveyor in mm: ~2.000 mm Width of conveyor in mm: ~1.100 mm Height of pallet conveyor: ~500 mm max pallet width for this conveyor: 800 mm max pallet length for this conveyor: 1200 mm max weight full pallet: 1500 kg Diameter of rollers in mm: ~80 mm Distance (pitch) between rollers in mm: ~150 mm Conveyor equipped with photoeyes on infeed/outfeed Input Power: 0,55 kW Voltage: 400 V, 3 Ph, 50 Hz

Build in 2004 Description/configuration: Complete line for automatic pallet strapping, automatic stretch-wrapping of pallets. Includes fully automated pallet conveying. Line with ""straight""-configuration, built with chain conveyors and configured as follows: > Straight chain conveyor, motorized, travel is long side leading, l~1100 mm, REF 25778.01 > pallet strapper Cyklop XZE-3111, REF 25778.30 > Straight chain conveyor, motorized, travel is long side leading, l~1100 mm, REF 25778.02 > Straight chain conveyor underneath wrapper, motorized, travel is long side leading, l~2600 mm, REF 25778.03 > ring style pallet film wrapper Cyklop GL 2000, REF 25778.40 > Straight chain conveyor, motorized, travel is long side leading, l~1100 mm, REF 25778.04 > Straight chain conveyor, motorized, travel is long side leading, l~1100 mm, REF 25778.04" Layout available max speed in pallets/h: 50 pallets/h Chain conveyor Pallet width of up to 800 mm Pallet length of up to 1200 mm max height full pallet (max passage height): ~1700 mm Height of pallet conveying (min=300mm): ~400 mm max weight full pallet: ~1500 kg Over all length equipment: ~8000 mm Over all width equipment: ~6000 mm Over all height equipment: ~3500 mm Input Power: ~15 kw (whole line) Voltage: 400 V, 3 Ph, 50 Hz Air requirement: 6 bar Equipment at central warehouse Helmstedt with nearest airports: Hannover (~1,5 hrs), Leipzig (~2hrs), Berlin (~2,5 hrs) Condition: cleaned & in working conditions Machine available: upon request

Built in 2001/2009  Pallet charge: Length 1.200 mm Width 800-1.000 mm Height 800-2.200 mm Wire diameter 76 mm Diameter of film reel max 400 mm Web width max 500 mm Film thickness 15-35 µm Equipment infeed belt strapping machine XZE 211 height of width max. 2.200 mm height of opening max. 2.400 mm belt guide distance 625 mm diameter of film reel 60 mm role division 65 mm conveying speed 8-15 m/min belt transfer speed 2,9 m/s belt clamping force of the strapping unit adjustable up to 3.200 N press capacity adjustable from 5 to 30 kN post-press time 30 seconds machine colour RAL 5003 control panel colour RAL 7032 noise level 91dB (A) nach DIN 45635 Teil 27 pallet rim width 800 mm length 1.200 mm height 500-1.300 mm weight up to 800 kg strapping material belt quality PET belt width 13 mm belt thickness 0,4-1,15 mm tandem plastic tape dispensers KAZ with locking unit stretch wrapper GL-1020-M

Machine number: 390400Built in: 2007Pallet dimensions A: 1.200 x 1.000 mmCharge dimensions: 1.200 x 1.000 mmFilm dimension: 1.350 x 850 mmPallet dimensions B: 1.200 x 800 mmCharge dimensions: 1.200 x 800 mmFilm dimension: 1.350 x 1.050 mmPallet direction: lengthwisePallet weight: max 2.000 kgPallet weight: 500 kgLoading height including pallet: max 1.800 mm, min 1.200 mmSpeed: up to 40 pallets/hEquipment •   roller conveyor•   pallet centering•   chain conveyorMSK Paratech•   film feeding MSK 340•   hood overcoat•   lifting system MSK 900•   MSK 280i Recotech•   guard•   electric cabinet

Pallet wrapping machine

Capacit: up to 35 pallets/h Film width: 500 mm Diameter: max 260 mm Core diameter: max 76 mm Film thickness: 17-30 mµ Equipment: • automatic pallet transport system • infeed belts • delivery belts • security fences

Built in: 1988
