Built in 1991 Size:  max 520 x 360 mm  min 120 x 100 mm Infeed height:  max 915 mm  min 515 mm Speed: max 25 - 160 m/min Speed: 30.000 c/h Equipment  Mobile knife unit VFZ 52 • Accessories • 1 set of operating manuals • 1 set of electrical diagrams • 1 set of tools • 1 spare part catalogue • Standard equipment

Suited for high volume addressing of cards, labels, and envelopes, or high-speed inline marking of packaging products. Depending on font, each print head can print up to 2 lines IBM PC compatible computer with Ethernet attachment to network (Included).

  Built in: 1990 Size: 350 x 321 mm Speed: 8.000 c/h Equipment:  stitching unit & trimmer:  • stitching unit 455  • 2 stitching heads  • trimmer  • 2 sets of knives

  Built in: 1991 Size: 450 x 320 mm Speed: 7.200 c/h

Inserting machines with film wrapping device

Size: max 270 x 425 x 70 mm; min 100 x 140 x 3 mmCover size: max 420 x 610 mm; min 140 x 203 mmSpeed: max 1.600 - 5.000 c/hPower requirements: 10,5 kW  (220/380V, 50Hz) Equipment                                    gathering machine•   12 stations•   3 feeders 201

Built in: 2008Size: max 320 x 320 mm; min 150 x 145 mmCover size: max 660 x 320 mm; min 225 x 135 mmBook block thickness: max 65 mmWeight: 2.100 kgCover thickness: 80-300 g/qmPile height: max. 150 mmSpeed: max 1.350 c/hType of current: 400/50 V/HzOverall dimensions: w x h x l  3.610 x 2.910 x 1.800 mm Equipment                                    perfect binder:•   4 clamps•   milling station with pressing roller•   hotmelt spine gluing unit•   hot melt side gluing unit•   PUR gluing unit•   Premelter for PUR gluing unit

Built in: 1999Size: max 480 x 320 x 80 mm; min 140 x 100 x 2 mmCover size: max 642 mm; min 203 mmBook block thickness: max 80 mm; min 2 mmSpeed: max 7.500 c/h; min 1.200 mmEquipment gathering machine•   hand feeding station•   21 feeders 3691/18•   reject gate 3614•   pile delivery Universo 244•   seperation element•   jogging elementperfect binder•   30 clamps•   PVA (cold glue) spine gluing unit•   hot melt side gluing unit•   IR intermediate dryer•   gauzing station•   stream cover feeder•   2 pressing stations•   HF dryeroptionales Equipment: --not included--•   PUR spine gluing unit•   premelter for PUR gluing unit

Built in: 2012Size: max 330 x 250 mmSize trimmed: max 330 x 250 mm; min 200 x 148 mmSize trimmed without lap: max 340 x 260 mmbooklet thickness: 4-6 mmMechanical  Speed: max 22.000 t/hEquipment crane systemgathering chain & feeder•   8 station gathering track•   ELTEX static device•   Feeder: 1 cover feeder•   6 feeder 416•   6 stream feeder 3738•   6 extentions for streamfeederstitching unit 410•   3 stitching headsthree knife trimmer•   three knife trimmer 304 knives•   2 sets of knives controlscontrolls•   automatic selfajusting calipers ASAC•   signature reading system ASIR•   Amrys•   Siemens controlcompensating stacker •  Robustooptional Equipment: --- not included ---•   additional feeders

Built in: 2011Size: max 320 x 485 x 60 mm; min 100 x 140 x 2 mmBlock hang-up: 8-15 mmMilling depth: max 4 mmClamp opening: max 80 mmPaper weight (grammage): min 60-170 g/qmCover width: 202-710 mmCover height Drum feeder: 140-490 mmCover height Stream feeder: 140-470 mmMechanical speed: 8.000 c/hEquipment gathering machine•   hand feeding station•   16 stations•   criss-cross deliveryperfect binder•   19 clamps•   milling station•   scoring station•   hot melt spine gluing unit•   hot melt side gluing unit•   PUR spine gluing unit•   2 premelters•   premelter for PUR gluing unit•   cover feederthree knife trimmer•   conveyor belt to trimmer with reject unit•   three knife trimmer Euro Trim Pro

Equipment  gathering machine • 6 stations • gatherer Ferag • reject unit • 2 jogging elements perfect binder • perfect binder Publica KM 410 • copilot with touch screen • 40 clamps • infeed incl. coupling with ZU • 2 milling stations • strip milling head • 4 spine preparation stations • hotmelt spine gluing unit • 2nd hotmelt spine gluing unit • hotmelt side gluing unit • 3 premelters • stream cover feeder SAL 411 • cover scoring 4 lines • 2 pressing stations • straight delivery • lay down device • quality control with individual product rejection conveyor system • length ca. 50 m • drying tower XAF • intermediate delivery • belt control cabinet TS.E three knife trimmer • three knife trimmer HD 152.P • right hand infeed with pre stacker • copilot with touch screen • cutting tables • knife adjustment device • 2 sets of knives compensating stacker • compensating stacker CB 16 • counting device • delivery right

Built in: 2001 Size: max 360 x 310 mm, min 140 x 100 mm Book block thickness: max 60 mm, min 3 mm Cover size: max 642 mm, min 203 mm Speed: max 18.000 c/h Equipment  gathering machine • chain tensioner • 18 feeders 3681 • reject gate 3714 controls • miss and double sheet control • ASAC automatic self-adjusting calipers intermediate elements • 2 jogging elements 3642 • connected with perfect binder • commander • 41 clamps • infeed chanel with jogger • 2nd milling station with pressing roller • double combined spine preparation station • 2 hot melt spine gluing units • hot melt side gluing unit • 3 premelters • SF stream cover feeder • SF cover nipping and pressing station • 2nd SF cover pressing station • smooth lay down device conveyor system • connected with • three knife trimmer Zenith S optionales Equipment:--not included-- • compensating stacker • shrink wrapping • palletizer

Baujahr 2005The Buhrs RF5 Mobile Rotary Feedercan be connected to or integrated into any Buhrs 4000 and many Buhrs Ultimail film packaging systems.The RF5 feeders can easily be placed in multiple positions such as left, in-line and right in the pick-up section of any Buhrs 4000 system and many Buhrs Ultimail film packaging systems.Key features of the Buhrs RF5 Mobile Rotary Feeder:Setting the timing on the flyMobile and flexibleMove from one position to another in just a second

Baujahr 2005The Buhrs RF5 Mobile Rotary Feedercan be connected to or integrated into any Buhrs 4000 and many Buhrs Ultimail film packaging systems.The RF5 feeders can easily be placed in multiple positions such as left, in-line and right in the pick-up section of any Buhrs 4000 system and many Buhrs Ultimail film packaging systems.Key features of the Buhrs RF5 Mobile Rotary Feeder:Setting the timing on the flyMobile and flexibleMove from one position to another in just a second

Built in: 2007 size main product: max 334 x 272 mm; min 194 x 145 mm size single feeder: max 334 x 272 mm; min 148 x 105 mm size twin feeder: max 320 x 272 mm; min 148 x 105 mm product thickness: max 13 mm blown air: 1,5 bar compressed air: 6 bar speed: max 30.000 c/h Equipment  • main product feeder • opening station • 6 insert stations • belt delivery optional equipment: --- not included --- • additional feeders • compensating book stacker • strapping machines • wrapping machines • Palletizer

Built in: 2007 Size: max 340 x 260 mm; min 90 x 115 mm Size (without lap): max 340 x 250 mm; min 90 x 115 mm lap: max 15 mm folio lap: min 6 mm low folio lap: min 8 mm Product size, stitching unit: max 340 x 260 mm; min 210 x 155 mm booklet thickness: max 6 mm Mechanical speed 1:1: max 25.000 t/h Mechanical speed 1:2: max 30.000 t/h Equipment  gathering chain & feeder • 8 station gathering track • 8 single base • 6 feeders 416 • product gluer 423 stitching unit • stitching unit 430 • 15" inch chain pitch • wire unwind device • thickness control/ plus-minus • 4 stitching heads three knife trimmer • three knife trimmer 426 knives • 2 knives delivery • compensating stacker Robusto optional Equipment: --- not included --- • crane system • bundle feeder • print roll feeder • additional stations • card gluer • div. conveyer belts • compensating stacker • strapping machines • wrapping machines • Palletizer

Built in: 2005 Size: max 510 x 310 x 60 mm, min 140 x 100 x 3 mm Book block thickness: max 60 mm, min 3 mm Cover size: max 642 mm, min 203 mm Speed: max 12.000 c/h Equipment: gathering machine • 18 stations • 18 feeder 3695/24 • reject gate 3614 • 2 jogging elements perfect binder • 22 clamps • clamp pitch 24" • jogging station • spine preparation • milling and roughening station • grinding station • hotmelt spine gluing unit • hotmelt side gluing unit • 2 premelters • stream cover feeder • SF cover pressing station • 2nd SF cover pressing station • lay down device three knife trimmer • conveyor belt to trimmer • Trimmer: MM Zenith-S

Built in: 2005 Size: max 510 x 310 x 60 mm, min 140 x 100 x 3 mm Book block thickness: max 60 mm, min 3 mm Cover size: max 642 mm, min 203 mm Speed: max 12.000 c/h Equipment gathering machine  •   18 stations  •   18 feeder 3695/24  •   reject gate 3614  •   2 jogging element   perfect binder  •   22 clamps  •   clamp pitch 24"  •   jogging station  •   spine preparation  •   milling and roughening station  •   grinding station  •   hotmelt spine gluing unit  •   hotmelt side gluing unit  •   2 premelters  •   stream cover feeder  •   SF cover pressing station  •   2nd SF cover pressing station  •   lay down device

Built in: 2012Size: max 480 x 330 mm; min 148 x 105 mmSpeed: max 30.000/18.000 c/hEquipment delivery left

Machine number: 338552-10 Built in: 2007 Size: max 320 x 470x 64 mm; min 102 x 152 x 7 mm Pile height pre-loading cage: 127 mm Pile height total stack: 330 mm Infeed height: 660 - 1.016 mm Speed: 15.000 c/h

Built in/YOC: 2009    Technical Data:  Format: min 145 x 200 mm; max 300 x 430 mm Stack height: max 50-300 mm Stack weight: max 18 kg Speed for strapped / film wrapped bundles: max 36 bundles/min Speed for loose bundles (only with Blocking Unit!): max 24 bundles/min Palletizing height (incl. pallet): max 1600 mm   Description:  Palletizing of strapped, film wrapped or loose (product permitting!!) bundles. With blocking unit for stable bundles. Infeed with turning device for variable rows which are combined to a layer. Each finished layer is then placed onto the pallet. Includes pallet conveying and empty pallet terminal. Equipment:  Palletizer:  · Simple palletizer (one line)  · Product orientation at infeed palletizer (standard): längs Blocking unit:  · Model: VB 95  · Serial Number: 446  · Infeed with flying cross (turning device) for bundles  · Right hand palletizer (palletizing to the right of the infeed)  Slip sheet dispenser:  Empty pallet dispenser:  · Model: PT  · Serial Number: 246  Pallet conveying:  · Pallet width (max): 1.000 mm  · 2 additional buffer positions for full pallets:  · Configuration of pallet conveying gerade All technical data is for information purposes only! Although the technical information is mostly taken from manufacturers documents, no guarantee can be given for correctness due to e.g. undocumented changes of the equipment. By no means are these values intended to be binding or part of the contract.

Delivery direction: Left & rightSize min: 480 x 330 mmSize max: 148 x 105 mmThickness min: 8 pagesThickness max: 20 mm / 400 pagesMechanical speed max: 16.000 cycles/hInfeed height max: 900 mmInfeed height min: 700 mmsimple operationsecure product infeedgentle handling on the turntableprotective product ejectionpost-route-deliverable packagespackages in layers and cross-stackedUser-friendly, compact control systemSecure production infeedReliable layer and stack formationGentle package ejection

Built in: 2006Size: max 480 x 330 mm; min 148 x 105 mmSpeed: max 30.000/18.000 c/hEquipmentdelivery right

Baujahr: 2007    Technische Daten:  Format: max 480 x 320 mm Formate unbeschnitten mit Nachfalz:  max 480 x 320 mm min 105 x 115 mm mit Zusatz 90 x 80 mm Formate unbeschnitten mit Vorfalz:  max 480 x 300 mm min 105 x 125 mm Mechanische Geschwindigkeit: Kettenteilung 21" 14.000 c/h Antriebsleistung: max 11 kW Druck-Vakuumpumpen: projektabhängig  Druckluft (bauseits): projektabhängig 6 bar Ausstattung: Sammelkette & Anleger: · 8 Stationen Sammelkette  Anleger: · 5 Anleger 370  Falzanleger: · 1 Falzanleger 1529  Heftstation: · 1 Heftstation 390  · 1 18" inch Kettenteilung  · 1 Übergabe rechts  · 1 Heftdraht-Abspulvorrichtung  · 1 Dickenkontrolle / Plus-Minus  · 1 Schrägbogen- und Längenkontrolle  Heftköpfe: · 2 Heftköpfe HK 75  Dreischneider: · 1 Dreischneider 449  Messer: · 2 Satz Messer  Standards: · 1 Standard Zubehör  · 1 Standard Werkzeug Zustand: · produktionsbereit  Verfügbar: · sofort  · Maschine kann in Produktion besichtigt werden Optionales Zubehör (nicht mit im Lieferumfang enthalten): · Zusätzliche Anleger  · Doppelnutzeneinrichtung  · Kreuzleger  · Kartenkleber  · Einsteckmaschinen  · Inkjetanlagen Auch wenn die technischen Daten mehrheitlich aus Herstellerbroschüren entnommen sind, bleiben sie unverbindlich und sind nicht Teil des Vertrages. Es wird keine Garantie für Vollständigkeit und Richtigkeit dieser Daten gegeben.
