Built in: 1999Size: max 480 x 320 x 80 mm; min 140 x 100 x 2 mmCover size: max 642 mm; min 203 mmBook block thickness: max 80 mm; min 2 mmSpeed: max 7.500 c/h; min 1.200 mmEquipment gathering machine•   hand feeding station•   21 feeders 3691/18•   reject gate 3614•   pile delivery Universo 244•   seperation element•   jogging elementperfect binder•   30 clamps•   PVA (cold glue) spine gluing unit•   hot melt side gluing unit•   IR intermediate dryer•   gauzing station•   stream cover feeder•   2 pressing stations•   HF dryeroptionales Equipment: --not included--•   PUR spine gluing unit•   premelter for PUR gluing unit

Built in: 2005 Size: max 510 x 310 x 60 mm, min 140 x 100 x 3 mm Book block thickness: max 60 mm, min 3 mm Cover size: max 642 mm, min 203 mm Speed: max 12.000 c/h Equipment gathering machine  •   18 stations  •   18 feeder 3695/24  •   reject gate 3614  •   2 jogging element   perfect binder  •   22 clamps  •   clamp pitch 24"  •   jogging station  •   spine preparation  •   milling and roughening station  •   grinding station  •   hotmelt spine gluing unit  •   hotmelt side gluing unit  •   2 premelters  •   stream cover feeder  •   SF cover pressing station  •   2nd SF cover pressing station  •   lay down device

Built in 2002 Size:  max 460 x 310 x 60 mm  min 125 x 100 x 3 mm Product thickness:  max 60 mm  min 3 mm Speed:  max 8.000 c/h  Equipment  gathering machine 18 stations gatherer ZU 840 gathering pockets with ATC (auto section thickness control) reject unit AS 840 Machine can be extended with more gatherers. controls missing and double sheet control intermediate elements jogging element Copilot 27 clamps milling and roughening station 2nd hotmelt spine gluing unit hotmelt side gluing unit 2 premelters stream cover feeder cover pressing station 2. cover pressing station lay down device

Built in: 1998/2008 Size:  max 460 x 310 x 60 mm  min 125 x 100 x 3 mm Product thickness:  max 60 mm  min 3 mm Speed:  max 8.000 c/h  Equipment  gathering machine: • 16 stations • gatherer ZU 804 intermediate elements: • reject unit • endsheet feeder • -connected with perfect binder: • 27 clamps • milling and roughening station • 1st hotmelt spine gluing base • intermediate drying unit • 2nd hotmelt spine gluing base • hotmelt spine gluing unit • hotmelt side gluing unit • 2 premelters • gauzing station • stream cover feeder • cover pressing station • 2. cover pressing station • lay down device

Built in: 2003 Size:  max 370 x 320 x 50 mm  min 140 x 105 x 2 mm Mechanical speed: 4.000 c/h Equipment  gathering machine: 2 additional handfed stations Wohlenberg Sprinter 7009 16 stations missing sheet and double sheet control criss-cross delivery perfect binder: 15 clamps spine preparation station milling and roughening unit dust extraction fume extraction hotmelt spine gluing unit hotmelt side gluing unit 2 premelters pile cover feeder plates-chain transport conveyor system standards: 1 set of operator manuals 1 set of electrical diagrams 1 set of standard tools 1 spare part catalogue

Installed 2000 Size:  max 510 x 310 x 60 mm  min 140 x 100 x 3 mm Book block thickness:  max 60 mm  min 3 mm Cover size:  max 642 mm  min 203 mm Speed:  max 12.000 c/h Equipment  gathering machine hand feeding station 18 stations feeders 3690 reject gate after the gathering machine reject gate 3614 controls ASAC automatic self-adjusting calipers intermediate elements spiral race away jogging element connected with perfect binder 21 clamps clamp pitch 24" infeed chanel with jogger milling and roughening station hot melt spine gluing unit hot melt side gluing unit premelter cover feeder SF cover nipping and pressing station smooth lay down device

Size:  max 320 x 260 x 40 mm  min 150 x 100 x 2 mm Book block thickness:  max 40 mm  min 2 mm Cover size:  max 560 x 325 mm  min 202 x 150 mm Speed:  max 5.000 c/h Power requirements 24 kW (220/380V, 50Hz) Length 7.543 mm Width 2.400 mm Equipment  gathering machine: chain tensioner with hand fed 20 stations missing sheet and double sheet control perfect binder 18 clamps milling and roughening unit hotmelt spine and side gluing unit pile cover feeder cover pressing station lay down device standards 1 set of operator manuals standard equipment information: condition: very nice machine in good working condition

Built in 1990 Size:  max 460 x 305 x 60 mm  min 140 x 103 x 2 mm Book block thickness:  max 60 mm  min 2 mm Cover size:  max 470 x 655 mm  min 140 x 210 mm Speed:  max 7.000 c/h Equipment  gathering machine: gatherer ZTM 370 x 20 missing sheet and double sheet control criss-cross delivery perfect binder: 26 clamps milling station spine preparation station dust extraction fume extraction hotmelt spine gluing unit 2nd hotmelt spine gluing unit hotmelt side gluing unit stream cover feeder 2. cover pressing station lay down device standards: 1 set of operator manuals 1 set of electrical diagrams 1 set of standard tools

Equipment: gathering machine: • chain tensioner with hand fed • 15 stations • criss-cross delivery perfect binder • 18 clamps • milling and roughening unit • hotmelt spine gluing unit • hotmelt side gluing unit • premelter • pile cover feeder • cover pressing station • gauzing station • 2. cover pressing station • stack delivery

Size max 510 x 305 x 60 mm Size min 140 x 100 x 3 mm Cover size max 642 mm Cover size min 203 mm Speed max 12.000 c/h Equipment  gathering machine •   18 stations •   18 feeders 3661-210 SF intermediate elements •   spiral race away •   jogging element perfect binder •   25 clamps •   clamp pitch 24" •   milling and roughening station •   hot melt spine gluing unit •   hot melt side gluing unit •   premelter •   SF stream cover feeder •   SF cover nipping and pressing station •   lay down device

Built in 2000 Size:  max 420 x 305 x 60 mm  min 200 x 240 x 4 mm Speed: max 6.000 c/h Equipment  gathering machine • chain tensioner • 16 stations • 16 feeders 1571 controls • miss and double sheet control intermediate elements • spiral race away • jogging element perfect binder • 18 clamps • infeed chanel with jogger • fold pressing station • milling and roughening station • hot melt spine gluing unit • hot melt side gluing unit • premelter • gauzing station • stream cover feeder • cover nipping and pressing station • lay down device standard accessories • 1 set of operator manuals • available: immediately  optionales Equipment:--not included-- • PUR spine gluing unit • premelter for PUR gluing unit

Built in 2000 Size max 370 x 320 x 50 mm min 140 x 105 x 2 mm Mechanical speed 4.000 c/h Equipment  gathering machine: • chain tensioner with hand fed • Wohlenberg Sprinter 7009 • 12 stations perfect binder • 15 clamps • milling and roughening unit • dust extraction • fume extraction • hotmelt spine gluing unit • hotmelt side gluing unit • 2 premelters • rotary cover feeder • belt delivery • lay down device • conveyor system optional equipment---not included--- • three knife trimmer • PUR gluing unit

Built in 2004 Size max: 430 x 320 x 60 mm Size: 140 x 100 x 3 mm working hours: 27.900 h Speed:max 5.000 c/h  Equipment  gathering machine • 18 stations • 18 feeder 1571 controls • ASIR automatic signature image reader • ASAC automatic self-adjusting calipers perfect binder • 20 clamps • double kombined spine preparation station • hotmelt spine gluing unit • hotmelt side gluing unit • rotary coverfeeder • cover scoring • cover pressing station • 2nd cover pressing station • lay down device optional equipment --- not included --- • PUR spine gluing unit • PVA (cold glue) spine gluing unit • conveyor belts to trimmer • trimmer Müller Martini Merit

Rebuilt: 2015 Size:  max 510 x 305 x 60 mm min 140 x 100 x 3 mm Cover size:  max 640 mm min 203 mm Speed max: 10.000 c/h  Equipment gathering machine: 18 feeders 210 controls: miss and double sheet control intermediate elements: spiral race away jogging element perfect binder: 20 clamps clamp pitch 24" milling and roughening station hot melt spine gluing unit hot melt side gluing unit 2 premelters S stream cover feeder S cover nipping and pressing station

Built in 1992 Size max 420 x 305 x 60 mm min 200 x 240 x 4 mm Speed max 6.000 c/h Equipment  gathering machine • 12 feeders 1531 intermediate elements • spiral race away perfect binder • 18 clamps • milling and roughening station • hot melt spine gluing unit • hot melt side gluing unit • premelter • pile cover feeder • cover nipping and pressing station • pile delivery optionales Equipment:--not included-- • extending of the gathering machine • modification of the conveyor belts • three knife trimmer

Built in 2001 Speed max 18.000 c/h Equipment  gathering machine • 32 stations • 32 feeders RG 318 D • reject gate after the gathering machine perfect binder • 36 clamps • clamp pitch 17 1/2 • infeed chanel with jogger • milling and roughening station • hot melt spine gluing unit • hot melt side gluing unit • 2 premelters • stream cover feeder • cover nipping and pressing station • smooth lay down device optionales Equipment:--not included-- • PUR spine gluing unit • premelter for PUR gluing unit

Built in: 1998 Size: max 460 x 310 x 60 mm min 125 x 100 x 3 mm Speed: max 6.000 c/h Equipment: gathering machine: • 16 stations • gatherer ZU 801 • -connected with perfect binder: • 17 clamps • milling and roughening station • brushing station • hotmelt spine gluing unit • hotmelt side gluing unit • 2 premelters • stream cover feeder • cover scoring • cover pressing station • smooth lay down device option - not included: • PUR spine gluing unit

  Rebuilt: 2005 Size: 510 x 305 x 60 mm Speed: 10.000 c/h Equipment: gathering machine: • 15 feeders 210 controls: • miss and double sheet control intermediate elements: • spiral race away • endsheet gluing unit 3610 • endsheet feeder with cold glue • endsheet pressing unit • jogging element perfect binder: • 35 clamps • clamp pitch 24" • jogging station • resting table • hot melt spine gluing unit • cam controlled • PVA (cold glue) spine gluing unit • hot melt side gluing unit • gauzing station • S stream cover feeder • cover scoring 2 to 6 lines • S cover nipping and pressing station • smooth lay down device conveyor system: • conveyor system 15 meter • 1 curve

Built in: 1997 Size: 460 x 310 x 60 mm Speed: 6.000 c/h Equipment:  gathering machine: • 16 stations • gatherer ZU 801 controls • missing and double sheet control intermediate elements • spiral raceway • hand fed • jogging element • criss-cross delivery • -connected with perfect binder • 21 clamps • jogging station • milling and roughening station • hotmelt spine gluing unit • hotmelt side gluing unit • premelter • gauzing station • stream cover feeder • cover scoring 2 to 6 lines • cover pressing station • lay down device • shingle conveyor delivery optionales Equipment:--not included-- • extending of the gathering machine • Opticontrol signature image reader • conveyer system ca. 20 m • three knife trimmer Kolbus HD 150

   Size: 510 x 290 x 65 mm Speed: 10.000 c/h Equipment:  gathering machine: • chain tensioner with hand feeding station controls: • missing and double sheet control intermediate elements: • spiral raceway • hand fed • jogging element • book block feeder • endsheet feeder perfect binder: • 32 clamps • jogging station • resting table • fold pressing station • milling and roughening station • hotmelt spine gluing unit • cam controlled • trolley spine gluing unit • PVA (cold glue) side gluing unit • premelter • gauzing station • stream cover feeder • cover scoring • cover pressing station • 2. cover pressing station • lay down device

  Built in: 1988 Size: 460 x 310 x 60 mm Speed: 6.000 c/h Equipment: gathering machine: • chain tensioner with hand feeding station • 16 stations controls: • missing and double sheet control intermediate elements: • spiral raceway • hand fed perfect binder: • 20 clamps • jogging station • resting table • fold pressing station • milling and roughening station • brushing station • hotmelt spine gluing unit • cam controlled • hotmelt side gluing unit • premelter • gauzing station • stream cover feeder • cover scoring 2 to 6 lines • cover pressing station • lay down device optional equipment - not included: • extending of the gathering machine • modification of the conveyor belts • three knife trimmer • compensating stacker • shrink wrapping • palletizer • optional equipment

Built in: 1990 Size: max 460 x 310 x 60 mm Speed: max 6000 c/h Equipment:  gathering machine: • chain tensioner with hand feeding station • 20 stations controls: • missing and double sheet control intermediate elements: • spiral raceway • hand fed perfect binder: • 25 clamps • jogging station • resting table • fold pressing station • milling and roughening station • brushing station • hotmelt spine gluing unit • cam controlled • hotmelt side gluing unit • premelter • gauzing station • stream cover feeder • cover scoring 2 to 6 lines • cover pressing station • 2. cover pressing station • smooth lay down device optional equipment - not included: • extending of the gathering machine • modification of the conveyor belts • three knife trimmer • compensating stacker • shrink wrapping • palletizer • optional equipment
