Machine number                           1070Built in                                           2009Infeed height                                 850 - 900 mmDelivery height                              850 - 900 mmbundle height                  max        300 mmProduct width                                148 - 315 mmProduct length                               210 - 430 mmProduct diagonal             max.       510 mm Cycle per layer                              0,9 s

Type: LS/1120Product size: Width min 200 mm, max 520 mm, lenght min 100 mm, max 320 mmProduct thickness: min 0,2 mm, max 4,5 mmStream thickness: max 25 mm (compressed)Shingle distance: 40 mm at normal max 80 mmEdge offset: +/- 3 mmFold orientation: Spine leading (inversed shingle stream)Page count: min 8 page, max 96 pagePaper wight: min 30 g/m2, max 140 g/m2Bundle lenght: min 600 mm, max 1200 mmEndboard: same as product size, Thickness min 9,5 mm, max 12,5 mmOperating speed: 24 sec. per bundleBelt speed: min 7,5 m/min, max 50 m/minStraping head: Mosca MK-43Strap material: 12 mm width poly propylene

Number of pages max 4-96Trimm cut-off max 3-50 mmPaper weight (grammage) max 4 pages/min 80 g/qmPaper weight (grammage) 8-48 pages/40-120 g/qmPaper weight (grammage) 64 pages/max 90 g/qmPaper weight (grammage) 72-96 pages/max 60 g/qmSize max 490 x 465 mmSize min 140 x 105 mmSpeed max 64.000 c/h

Number of pages max 4-96Trimm cut-off max 3-50 mmPaper weight (grammage) max 4 pages/min 80 g/qmPaper weight (grammage) 8-48 pages/40-120 g/qmPaper weight (grammage) 64 pages/max 90 g/qmPaper weight (grammage) 72-96 pages/max 60 g/qmSize max 490 x 465 mmSize min 140 x 105 mmSpeed max 64.000 c/h

“A“ Dimension 102 mm, 320 mm“B“ Dimension 145 mm, 500 mm“D“ Dimension limited by “A“ & “B“ limited by “A“ & “B“Thickness 4 pages 57 g/m, 96 pages 57 g/mSpeed product permitting 90 000 products per hourStack height RS 34S-17 upper bin total stack 254 mm 432 mmProduct orientation Spine leading (preferred), spine to the side (product permitting)Weight 945 kg (2100 lb)Optionsleft / right delivery, servo turntable, high-infeed

Built in: 2007 Size: max 480 x 320 mm; min 200 x 110 mm bar length (pressed): max 1200 mm; min 800 mm Type of pallet: Euro pallet  Cycle time: min 30 s/unit Air requirement: 10 Nm3/h @ 6 bar Electrics: 380 VAC Electrics: 3 PH Electrics: 50 Hz Electrics: 5,5 kW Dimensions (L x W x H): 2000 x 3000 x 3100 mm Weight: 2000 kg

Built in: 2007 Size: max 480 x 320 mm; min 200 x 110 mm Mech. Speed: 1,0 m/s  Air requirement (6 bar): 5 m³/h Weight: 4.100 kg (approx.) Equipment • delivery left Strapping system • Mosca

Built in 2014  - Performance/Speed: 55.000 cph (product permitting) - min format product (head/foot x spine): 102 mm x 152 mm (4.00" x 6.00") - max format product (head/foot x spine): 321 mm x 500 mm (12.63" x 19.68") - max pagination: 64p tab & magazine, 32p digest & delta - Product orientation: Spine leading - Low Infeed  - Infeed height (min/max in mm): 500-1000 mm  - Waste gate  - Stream Aligner / Jogger - Single squeeze roller  - Laser Counter, model: Scatec-2 - Upper bin height in mm: 127 mm - Upper Bin with Flipper Fingers  - Turntable with compression plates - max Stack height in mm: 330 mm - Pneumatic turntable - Pneumatic pusher - Delivery Direction to the right - Delivery height in mm: 876 mm (34.50“) - Delivery Table included  - Over all length equipment: 2514-2759 mm - Over all width equipment: ~700 mm - Over all height equipment: ~1800-1950 mm - Input Power: 3 kVA - Voltage: 400 V, 3 Ph, 50/60 Hz - Air requirement: 110 l/min @ 5.5 bar (6 cfm @ 80 psi) - Weight: 900 kg (2000 lb) - Equipment at warehouse Helmstedt, airports: Hannover (~1 hr), Berlin (~2 hrs) - Condition: cleaned & in working conditions

Size: max 500 - 330 mm; min105 - 140 mm Size (diagonal): max 560 mm Number of pages: max 128 St.; min 4 St. Pile height: max. 300 mm section height: max 200 mm Infeed height: 560 – 970 mm Delivery height: 887 mm Cycle per layer: 1,2 - 1,5 s Air consumption: 1.020 Nl/min (@ 1 bar) Voltage: 400, 3~, N, PE V Sicherung: 25 A Frequency: 50 Hz Length: 3.372 mm Width: 1.038 mm Height: 2.056 mm Weight: ca. 1.400 kg Optional equipment: not included! Blocking device VM 500

Built in: 1995 Product dimensions: max 480 x 320 mm; min 200 x 110 mm bar length: 800-1200 mm Type of pallet: Euro pallet .  Pallet height (incl. pallet): max 1450 mm Cycle time: min 30 s/unit Air requirement: 10 Nm3/h @ 6 bar Electrical: 380 VAC Electrical: 50 Hz Electrical power: 5,5 kW Dimensions (L x W x H): 2000 x 3000 x 3100 mm Weight: 2000 kg Equipment control • Siemens • Palette despencer • Pallet conveyor line

Size:  max 500 x 330 mm  min 140 x 150 mm Product thickness:  side 4-96 Seiten Speed:  max 100.000 Ex./h Pile height 300 mm Infeed height 500-1920 mm Delivery height 890 mm Power requirements 2 kW (220/380V, 50Hz) Length 3077 mm Width 894 mm Height 1835 mm Weight 960 kg (approx.)

Built in 2002 Equipment: Automatic rotary cutting line consisting of: 4 rotary cutters /Trimmers, Gämmerler RS134/D , 2 press stations, Gämmerler PS300, 3 lifting table elements, Büter, 4 adjustable corner-curve units, conveyor belts and feeder belts,

Built in: 2002 bar length: 600 - 1.200 mm Sheet size: max 490 x 320 mm; min 220 x 150 mm Mechanical cycle time: min 24 s Effektive cycle time: min 30 s infeed height: adjustable 250 - 550 mm Log delivery height: 1.150 mm Paper weight (grammage): max 40 - 130 g/qm Electric supply: 400/50 V/Hz/A Air requirement (6 bar): 5 m³/h Weight: 4.100 kg (approx.)  Equipment delivery • delivery right • automatic wood inserter palletizer • pallet dispenser • transport rollers

Built in: 2002 bar length: 600 - 1.200 mm Sheet size: max 490 x 320 mm; min 220 x 150 mm Mechanical cycle time: min 24 s Effektive cycle time: min 30 s infeed height: adjustable 250 - 550 mm Log delivery height: 1.150 mm Paper weight (grammage): max 40 - 130 g/qm Electric supply: 400/50 V/Hz/A Air requirement (6 bar): 5 m³/h Weight: 4.100 kg (approx.) Equipment delivery • delivery left • automatic wood inserter palletizer • pallet dispenser • transport rollers

- Speed: up to 100.000 cph / 80 m/min (product permitting) - min width product: ~122 mm - max width product: ~530 mm - min length product: ~122 mm - max pagination product: 4-96p (product permitting) - max thickness shingled stream: up to 13 mm - infeed stream lap: ~25-100 mm - min trim width: ~5 mm - max trim width: ~65 mm - min product width after trim: ~118 mm - Trimmming line with 1st trimmer - right bump turn - 2nd trimmer - Infeed/delivery height: ~800 mm - Trimming line - 1st trimmer knife left - Trimming line - 2nd trimmer knife left & right - To be used with segmented knives - Over all length equipment: ~1675 mm - Over all width equipment: ~1530 mm - Over all height equipment: ~1160 mm - Input Power: 7,5 kW - Voltage: 400 V, 3 Ph, N, PE - Air requirement: practically no air requirement - Suction capacity per nozzle: 900 m3/h, air speed 31m/s - Weight: ~1100 kg per trimmer - Optional equipment: second EM 130 bump turn - Equipment at Helmstedt, airports: Hannover (~1 hr), Berlin (~2 hrs) - Mechanical / electrical machine test possible (option) - Condition: in working conditions - Machine available: upon request Description: Complete trimming line with 2 trimmers RS 134 and a bump turn EM 130

Built in: 2001 Product dimensions: max 480 x 320 mm; min 200 x 110 mm bar length: 800-1200 mm Type of pallet: Euro pallet .  Pallet height (incl. pallet): max 1450 mm Cycle time: min 30 s/unit Air requirement: 10 Nm3/h @ 6 bar Electrical: 380 VAC Electrical: 50 Hz Electrical power: 5,5 kW Dimensions (L x W x H): 2000 x 3000 x 3100 mm Weight: 2000 kg

Built in: 2001 Size: max 480 x 320 mm; min 200 x 110 mm Mech. Speed: 1,0 m/s  Air requirement (6 bar): 5 m³/h Weight: 4.100 kg (approx.) Equipment  • delivery right  Strapping system • Strapex

Built in: 2002 - Speed: up to 100.000 cph / 80 m/min (product permitting) - min width product: 101 mm - max width product: 530 mm - min length product: 114 mm - max height / thickness / pagination product: 2-64p(96p) - product permitting - infeed stream lap: ~25-100 mm - min width product: ~3 mm - max width product: ~50 mm - min product width after trim: ~95 mm - Trimmming line with 1st trimmer - right bump turn - 2nd trimmer - Infeed/delivery height: probably ~600 mm >>TBC  - Trimming line - 1st trimmer knife left & right - Trimming line - 2nd trimmer knife right - To be used with carbide ring knives - Optional equipment: additional RS 220 bump turn, REF 25981.01, S/N 220-1137 - Over all length equipment: ~3500 mm - Over all width equipment: ~3000 mm - Over all height equipment: ~1181 mm (@ infeed height~800 mm) - Input Power: ~13 kW - Voltage: 400 V, 3 Ph, N, PE, 50 Hz - Air requirement: practically no air requirement - Suction capacity per nozzle: 900 m3/h, air speed 31m/s - Weight: ~800 kg - Color: RAL 7035, light grey - Equipment at central warehouse Helmstedt with nearest airports: Hannover (~1 hr),  - Mechanical / electrical machine test possible - Description: Right hand trimming line with 2 trimmers and a bump turn in between. For 3-side trim of products in a shingled stream. - Condition: cleaned & in working conditions - Machine available: upon request

Built in: 1997 Size: max 480 x 320 mm; min 200 x 110 mm Mech. Speed: 1,0 m/s  Air requirement (6 bar): 5 m³/h Weight: 4.100 kg (approx.) Equipment  • delivery right

Built in: 2003 Size: max 320 x 500 mm min 102 x 145 mm Pile height pre-loading cage: 210 mm Pile height total stack: 330 mm Infeed height: 546-1.270 mm Stream distance: 19-102 mm Delivery height: 876 mm Speed: max 120.000 E. Ex./h Equipment:  • infeed with reject unit • double pressing unit • infrared counter • digital display • delivery to the right or left programmable • delivery belt

Built in 2004  Speed: 90.000 cph (product permitting) - min format product (head/foot x spine): 102 mm x 145 mm (4.00" x 5.75") - max format product (head/foot x spine): 320 mm x 500 mm (12.63" x 19.68") - max pagination: 48p - Product orientation: Spine leading - Low Infeed  - Infeed height (min/max in mm): 600-1200 mm - Waste gate  - Stream Aligner / Jogger - Single squeeze roller  - Laser Counter, model: Baumer Scatec-1 - Upper bin height in mm: 210 mm - Upper Bin with 3 forks - Turntable with compression plates - max Stack height in mm: 330 mm - Servo turntable - Pneumatic pusher - Delivery Direction to the right - Delivery height in mm: 876 mm (34.50“) - Air Delivery Table included  - Over all length equipment: 2650-2950 mm - Over all width equipment: ~700 mm - Over all height equipment: ~1800-1950 mm - Input Power: 3 kVA, 50/60 Hz, 3 ~ - Air requirement: 170 l/min @ 5.5 bar (6 cfm @ 80 psi) - Weight: 945 kg (2100 lb) - Equipment at Helmstedt, airports: Hannover (~1 hr), Berlin (~2 hrs) - Mechanical / electrical machine test possible - Condition: cleaned & in working conditions

Rebuilt: 2008 Size: max 320 x 470 mm; min 133 x 152 mm Product thickness: max 96 Seiten 57 g/m² mm Pile height pre-loading cage: 127 mm Pile height total stack: 330 mm Infeed height: 470 - 1.146 mm Delivery height: 876 mm Speed: max 100.000 Ex./h Equipment • infeed with reject unit • double pressing unit • infrared counter • delivery to the left • delivery belt Condition: cleaned and checked

In line stitching unit for Web Offset Presses
