Size untrimmed: max 320 x 490 mm; min 103 x 140 mmSize trimmed: max 307 mm; min 100 mmCover weight: 100 - 350 g/m²Speed: 1.000 - 6.000 Takte/minPower requirement: 10 kWWeight: 3.800 kgEquipment•   2 set of knives

Built in: 2012Machine speed: max. 100 products/minuteTurning movement speed: max. 55 turns/minuteProduct (L x W x H): min. 130 × 100 × 3 mm; max. 480 × 330 × 80 mmPre-stacking station height: max. 80 mm Pile height: max. 210 mm

SPECIFICATIONSSpeed 6,000cphMax block width 320mmMax block height 450mmMax block thickness 60mmSignature grammage 60–170gsm

Size: max 320 x 384 mm Size trimmed: max 304 x 310 mm, min 70 x 136 mm Speed: max 4.000 c/h, min 1.000 mm Power requirements: 7 kW (220/380V, 50Hz) Air requirement (6 bar): 40 m³/h Width: 3.612 mm Depth: 1.970 mm Height: 2.020 mm Weight: 3.500 kg (approx.) Equipment: • belt feeding • automatic infeed with integrated pre stacker • make-ready system • silicone spraying device • external knife changing device • equipment for changing the format: • 1 set of pressing plates & holders • 1 set of table quick change plates • 3 sets of cutting sticks • 2 set of knives • central lubrication • belt delivery • 1 set of operator manuals • 1 set of electrical diagrams • 1 set of standard tools • 1 spare part catalogue • standard equipment

Built in: 2002 Size trimmed: max 300 x 400 mm, min 85 x 115 mm Size untrimmed: max 320 x 460 mm, min 100 x 125 mm Speed: max 6.600 c/h Equipment: • automatic infeed with integrated counter stacker • cut counter • offcut blower • 1 set of clamping plates and holders • 1 set of plate tables • 3 sets of cutting sticks • 2 sets of knives • external device for knife changing including setting gauge • central lubrication system • 1 set of operator manuals • 1 set of electrical diagrams • 1 set of standard tools • standard equipment

Built in 2002 Size: max 310 x 400 x 80 mm Size trimmed: max 300 x 388 x 80 mm; min 100 x 120 x 2 mm Speed: max 6.000 c/h Feeding height: max 80 mm Air requirement (6 bar): 30 m³/h Length: 2.300 mm Width: 2.200 mm Height: 2.500 mm Weight: 5.700 kg (approx.) Equipment  copilot right hand infeed electronic counter 2 sets of knife holders 2 set of knives equipment for changing the format: 1 set of pressing plates & holders 1 set of size extensions 1 set of quick change tables 3 sets of cutting sticks Motorische Formateinstellung automatic setting from: - infeed device - book block pressure - cutting table - side knives - side gauges central lubrication standard accessories further information condition: as is, cleaned available: immediately

Built in 1997 Size: max 450 x 340 mm, min 140 x 100 mm Product thickness: max 70 mm, min 3 mm Infeed height: max 890 mm, min 800 mm Delivery height: 850 mm Speed: max 18.000 c/h Power requirements 1,35 kW (220/380V, 50Hz) Length 2.208 mm Width 1.500 mm Height 1.700 mm Weight 1.000 kg (approx.)

Built in 1990 Size:  max 450 x 340 mm  min 140 x 100 mm Product thickness:  max 70 mm  min 3 mm Infeed height:  max 890 mm  min 800 mm Delivery height 850 mm Speed:  max 18.000 c/h Power requirements 1,35 kW (220/380V, 50Hz) Length 2.208 mm Width 1.500 mm Height 1.700 mm Weight 1.000 kg (approx.)

Built in: 1998 Size:  max 310 x 400 x 80 mm Size trimmed:  max 300 x 388 x 80 mm  min 100 x 120 x 2 mm Speed:  max 6.000 c/h Feeding height:  max 80 mm Air requirement (6 bar) 30 m³/h Length: 2.300 mm Width: 2.200 mm Height: 2.500 mm Weight: 5.700 kg (approx.)

Built in 2003 Mechanical speed 900 - 2700 t/h Product height trimmed 145 - 380 mm Product widthtrimmed 100 - 300 mm Product thickness min 2 mm Feeding height 10 - 100 mm Equipment  • infeed belt from the right side • automatic infeed with integrated counter stacker • silicone spraying device • central lubrication • belt delivery • equipment for changing the format: • 1 set of clamp plates & plate holders • cutting plates 2-7 • 1 set cutting table plates • 3 sets of cutting sticks • 2 sets of knives • external knife changing device • 1 set of operator manuals • 1 spare part catalogue • standard equipment • 1 set of electrical diagrams • 1 set of standard tools • Condition: good working

Built in 1998 Size max 305 x 420 mm Size trimmed: max 300 x 400 mm  min 100 x 100 mm Book block thickness:  max 80 mm  min 2 mm Feeding height 80 mm Speed max 3.900 c/h Length 2.400 mm Width 3.060 mm Height 1.740 mm Weight 5.290 kg (approx.) Equipment  • automatic infeed with integrated pre stacker • gripper loading • cut counter • automatical speed regulation • offcut blower • Equipment for sheet-fed • 1 set of clamping plates and holders • 1 set cutting table • 3 sets of cutting sticks • 2 set of knives • automatic lock of knife adjustment and pressing block • external knife changing device • copilot • automatic setting of • - infeed device • - bookblock pressure • - cutting table • - side knives • - side gauges • - height of the delivery clamp • central lubrication • delivery clamp

Built in 1997 Size max 300 x 300 mm min 105 x 148 mm Cutting thickness 2 - 50 mm Speed max 1.020 c/h

Size: max 460 x 315 mm Size trimmed:  max 430 x 300 mm  min 80 x 50 mm False opening: max 140 mm Feeding height: max 120 mm Speed: max 1.500 c/h Power requirements: 3 kW (220/380V, 50Hz) Motor: max 220/380 V Motor: 50 Hz Width: 2.050 mm Depth: 2.220 mm Height: 1.615 mm Weight: 2.550 kg (approx.) Equipment:  automatic infeed with integrated counter stacker • 1 set of clamp plates & plate holders • 1 set cutting table extension • 1 set cutting table plates • 3 sets of cutting sticks • 2 sets of knives • 1 set of operator manuals • 1 spare part catalogue • standard equipment • 1 set of electrical diagrams • 1 set of standard tools

Built in 1996 Size max 304 x 340 mm min 146 x 103 mm Speed max 7.000 c/h Equipment  • 2 sets of knife holders • 2 set of knives • equipment for changing the format: • 1 set of pressing plates & holders • 1 set of quick change cassettes standard size

Built in 2004 Size:  max 384 x 340 mm  min 140 x 103 mm Size trimmed:  max 304 x 310 mm  min 136 x 100 mm Book thickness:  max 70 mm  min 2 mm Speed: max 1.000-7.000 c/h Power requirement: kW 14 kW Compressed air: 40 Nm³/h bei 6 bar Width: 3.612 mm Depth: 2.950 mm Height: 2.030 mm Weight: 4.000 kg (approx.) Equipment  equipment for changing the format: - 1 set of pressing plates & holders - 1 set of size extensions - 1 set of table quick change plates - 3 sets of cutting sticks - 2 set of knives

Built in 2001 operating voltage 230/400 V; 3~  operating voltage 50 Hz

Built in: 1993 Size:  max 350 x 440 mm min 146 x 103 mm Size trimmed:  max 310 x 420 mm min 140 x 100 mm Product thickness:  max 70 mm min 3 mm Speed:  max 6.600 c/h Equipment: •   infeed belt  •   automatic infeed with integrated pre stacker  •   electronic counter  •   external knife changing device  •   2 set of knives  •   equipment for changing the format:  •   1 set of  pressing plates & holders  •   1 set of table size extensions  •   1 set of quick change cassettes standard size  •   3 sets of cutting sticks

Built in 1989 Size max 320 x 400 mm Size trimmed max 305 x 380 mm Size trimmed 100 x 125 mm Product thickness max 80 mm min 6 mm Speed max 6.000 c/h Feeding height max 80 mm Equipment  • infeed from the right side • automatic infeed with integrated pre stacker • cut counter • equipment for sheet-fed • 1 set of clamping plates and holders • 3 sets of cutting sticks • 2 set of knives • external knife changing device • central lubrication • belt delivery

Size: max 460 x 350 mm Size: min 70 x 50 mm Speed: max 25 c/min Infeed height: 120 mm False opening: max 160 mm Speed: kW 7,5 kW

Size max 500 x 320 x 80 mm Speed max 16.000 c/h

Built in 1998 Size min 102 x 152 x 7 mm max 320 x 470 x 64 mm Speed max up to 15.000 Prod./h Table height 876 mm

Built in 2001 Size min 102 x 152 x 7 mm max 320 x 470 x 64 mm Speed max up to 15.000 Prod./h Table height 876 mm
