Built in                                          2019Technical Data·         Strapping capacity: up to 15 single straps/minute·         Parallel strapping capacity: up to 5 bundles/minute·         Frame size (W x H): 600 x 500 mm·         Maximum bundle weight: 25 kg·         Strapping material: Polypropylene (PP)·         Strap width: 5 - 12 mm·         Strap thickness: 0.35 - 0.70 mm·         Seal type: Thermal weld seal·         Coil core diameter: 200 / 228 mm·         Coil outside diameter: approx. 450 mm·         Electrical supply: 230 V, 1 Phase, 50 Hz·         Power consumption: 1.1 kW·         Pneumatic pressure: 4 bar·         Air consumption: 90 l/min (approx. 3 l/strap)·         Strap tension: up to 200 N·         Conveyor speed: 26 - 59 m/min·         Machine weight: 306 - 420 kg (depending on configuration)Standard Features·         Fully automatic operation·         PLC control with touchscreen interface·         Automatic strap feeding and detection·         Variable conveyor speed·         Adjustable strap tension ·         Maintenance-free direct drives
